DYNAMIC VISCOSITY VALUES
General Dynamic Viscosity Table通用动态粘度表
This table presents nominal data. Actual values, provided with each standard, may vary slightly from lot to lot and formulations are subject to change. If your application requires close conformity with published nominal values, please contact technical service to obtain the actual viscosity values associated with the current formulation.
| Catalog Number | Viscosity Standard | 40 °F 4.44 °C |
20 °F -6.67 °C |
68 °F 20 °C |
77 °F 25 °C |
100 °F 37.78 °C |
104 °F 40 °C |
122 °F 50 °C |
140 °F 60 °C |
176 °F 80 °C |
210 °F 98.89 °C |
212 °F 100 °C |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 9727-C10 | N.4† | — | — | 0.32 | 0.30 | 0.28 | 0.27 | — | — | — | — | — |
| 9727-C15 | N.8† | — | — | 0.64 | 0.60 | 0.52 | 0.51 | — | — | — | — | — |
| 9727-C20 | N1.0† | — | 2 | 0.93 | 0.86 | 0.72 | 0.70 | 0.62 | — | — | — | — |
| 9727-C22 | N2 | — | — | 2.2 | 2.0 | 1.6 | 1.5 | 1.3 | — | 0.85 | 0.66 | 0.65 |
| 9727-C25 | S3 | — | — | 3.9 | 3.3 | 2.5 | 2.4 | 1.9 | — | 1.2 | 0.90 | 0.90 |
| 9727-C27 | N4 | — | — | 5.2 | 4.5 | 3.3 | 3.1 | 2.5 | — | 1.4 | 1.1 | 1.1 |
| 9727-C30 | S6 | — | — | 10 | 8.0 | 5.3 | 5.0 | 3.8 | — | 2.0 | 1.5 | 1.5 |
| 9727-C31 | N7.5 | — | — | 11 | 9.5 | 6.3 | 5.9 | 4.5 | — | 2.4 | 1.7 | 1.7 |
| 9727-C32 | N10 | — | — | 21 | 16 | 9.5 | 8.8 | 6.3 | — | 2.9 | 2.1 | 2.0 |
| 9727-C34 | N14 | 1,400 | — | 24 | 20 | 12 | 11 | 8.2 | — | 3.8 | 2.7 | 2.6 |
| 9727-C35 | S20 | — | — | 37 | 29 | 17 | 15 | 11 | — | 4.6 | 3.0 | 3.0 |
| 9727-C36 | N26 | — | — | 47 | 37 | 22 | 20 | 14 | — | 6.2 | 4.1 | 4.0 |
| 9727-C37 | N35 | — | — | 75 | 56 | 30 | 27 | 18 | — | 7.1 | 4.5 | 4.4 |
| 9727-C38 | N44 | — | — | 92 | 71 | 39 | 36 | 24 | — | 9.5 | 6.0 | 5.9 |
| 9727-C40 | S60 | — | — | 141 | 104 | 52 | 47 | 30 | — | 10 | 6.4 | 6.2 |
| 9727-C41 | N75 | — | — | 170 | 125 | 68 | 61 | 41 | — | 16 | 9.5 | 9.2 |
| 9727-C42 | N100 | — | — | 283 | 202 | 95 | 84 | 52 | — | 16 | 9.5 | 9.2 |
| 9727-C43 | N140 | — | — | 340 | 250 | 130 | 120 | 74 | — | 25 | 15 | 14 |
| 9727-C45 | S200 | — | — | 460 | 340 | 170 | 150 | 98 | — | 31 | 18 | 18 |
| 9727-C46 | N250 | — | — | 650 | 480 | 230 | 210 | 130 | — | 41 | 23 | 23 |
| 9727-C47 | N350 | — | — | 820 | 600 | 300 | 260 | 150 | — | 49 | 25 | 25 |
| 9727-C48 | N415 | — | — | 1,200 | 830 | 390 | 350 | 210 | — | 62 | 34 | 33 |
| 9727-C50 | S600 | — | — | 1,500 | 1,100 | 490 | 450 | 260 | — | 75 | 40 | 39 |
| 9727-C51 | N750 | — | — | 2,200 | 1,600 | 710 | 620 | 370 | — | 100 | 55 | 53 |
| 9727-C52 | N1000 | — | — | 2,900 | 2,000 | — | 800 | 460 | 280 | 120 | — | 65 |
| 9727-C53 | N1400 | — | — | 4,300 | 3,000 | — | 1,200 | 680 | 420 | 180 | — | 92 |
| 9727-C55 | S2000 | — | — | 7,300 | 4,700 | 1,700 | 1,400 | 700 | — | 140 | 62 | 59 |
| 9727-C56 | N2500 | — | — | 9,000 | 6,000 | — | 2,100 | 1,100 | 630 | 240 | — | 110 |
| 9727-C57 | N4000 | — | — | 17,000 | 11,000 | — | 2,900 | 1,400 | 730 | 250 | — | 100 |
| 9727-C58 | N5100 | — | — | 25,000 | 16,000 | — | 4,500 | 2,100 | 1,100 | 360 | — | 140 |
| 9727-C60 | S8000 | — | — | 33,000 | 20,000 | 7,000 | 5,900 | 2,800 | — | 450 | — | 200 |
| 9727-C61 | N10200 | — | — | 52,000 | 32,000 | — | 9,000 | 4,200 | 2,100 | 660 | — | 250 |
| 9727-C62 | N15000 | — | — | 68,000 | 41,000 | — | 11,000 | 5,400 | 2,600 | 840 | — | 320 |
| 9727-C63 | N18000 | — | — | 92,000 | 57,000 | — | 16,000 | 7,500 | 3,800 | 1,140 | — | 420 |
| 9727-C65 | S30000 | — | — | — | 71,000 | 23,000 | 20,000 | 9,300 | — | 1,400 | — | 540 |
† Incurs additional shipping charges due to low flash point
