High-Temperature Viscosity Standards高温粘度标准
This table presents nominal data. Actual values, provided with each standard, may vary slightly from lot to lot and formulations are subject to change. If your application requires close conformity with published nominal values, please contact technical service to obtain the actual viscosity values associated with the current formulation.
Nominal viscosity values of high-temperature viscosity standards
| Catalog Number | Viscosity Standard | Type | ASTM Methods | Dynamic viscosity in mPa·s (cP) | ||
|---|---|---|---|---|---|---|
| 80 °C | 100 °C | 150 °C | ||||
| 9727-U45 | HT22* | Newtonian | D5481 | — | 3.5 | 1.5 |
| 9727-U50 | HT39* | Newtonian | D5481 | — | 4.7 | 2.0 |
| 9727-U55 | HT75* | Newtonian | D5481 | — | 7.0 | 2.7 |
| 9727-U60 | HT150* | Newtonian | D5481 | — | 10.5 | 3.7 |
| 9727-U65 | HT240* | Newtonian | D5481 | — | 15.4 | 5.0 |
| 9727-U70 | HT390* | Newtonian | D5481 | — | 23.5 | 7.0 |
| 9727-U92 | HTNN-1† | Non-Newtonian | D5481, D4741, D4683 | — | — | 3.6 |
| 9727-U94 | HTNN-2† | Non-Newtonian | D5481, D4741, D4683 | — | — | 3.1 |
| 9727-R05.32 | HT22*¥ | Newtonian | D4741 | — | 3.5 | 1.5 |
| 9727-R10.032 | RL 102*¥ | Newtonian | D4741 | 8.4 | 4.1 | 1.8 |
| 9727-R15.032 | RL 103*¥ | Newtonian | D4741 | 12.8 | 6.1 | 2.4 |
| 9727-R20.032 | RL 104*¥ | Newtonian | D4741 | 18.0 | 9.8 | 3.6 |
| 9727-R25.032 | RL 105*¥ | Newtonian | D4741 | 25.5 | 12.8 | 4.4 |
| 9727-R30.032 | RL 106*¥ | Newtonian | D4741 | 26.9 | 15.3 | 5.2 |
| 9727-R35.032 | RL 107*¥ | Newtonian | D4741 | 36.8 | 17.4 | 5.8 |
| 9727-R62.032 | RL 232†¥ | Non-Newtonian | D5481, D4741, D4683 | — | 6.2 | 3.2 |
| 9727-P10 | R-100*‡ | Newtonian | D4683, D6616 | 3.5 | 2.4 | 1.2 |
| 9727-P15 | R-200/R-2200*‡ | Newtonian | D4683, D6616 | 5.1 | 3.4 | 1.5 |
| 9727-P20 | R-300/R-2300*‡ | Newtonian | D4683, D6616 | 8.0 | 4.8 | 1.8 |
| 9727-P25 | R-350/R-2350*‡ | Newtonian | D4683, D6616 | 12.5 | 7.2 | 2.7 |
| 9726-P30 | R-400/R-2400*‡ | Newtonian | D4683, D6616 | 18.1 | 10.0 | 3.6 |
| 9727-P35 | R-450/R-2450*‡ | Newtonian | D4683, D6616 | 24.0 | 13.5 | 4.1 |
| 9727-P40 | R-500*‡ | Newtonian | D4683, D6616 | 27.0 | 14.5 | 5.0 |
| 9727-P45 | R-600*‡ | Newtonian | D4683, D6616 | 46.0 | 23.5 | 7.0 |
* Density values provided at all test temperatures for indicated standard
† Data provided at an apparent shear rate of 1 x 106s-1
¥ Sold in 1 liter can only
∧ Sold in 0.5 liter, 1 liter and 4 liter sizes
‡ Viscosity data also provided at 40 °C and 120 °C
