Nominal Viscosity Values of High Viscosity Standards高粘度标准的标油粘度值
This table presents nominal data. Actual values, provided with each standard, may vary slightly from lot to lot and formulations are subject to change. If your application requires close conformity with published nominal values, please contact technical service to obtain the actual viscosity values associated with the current formulation.
| Catalog Number | Viscosity Standard | Dynamic viscosity in mPa·s (cP) | Kinematic viscosity mm²/s (cSt) | |||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 20 °C 68 °F |
25 °C 77 °F |
40 °C 104 °F |
60 °C 140 °F |
135 °C 275 °F |
60 °C 140 °F |
100 °C 212 °F |
135 °C 275 °F |
|||
| 9727-E10 | N600* | — | 1100 | — | 160 | 15 | 200 | — | 22 | |
| 9727-C52 | N1000†* | 2900 | 2000 | 800 | 280 | — | 350 | 80 | — | |
| 9727-E15 | N2000* | — | 4900 | — | 380 | 21 | 440 | — | 26 | |
| 9727-C57 | N4000†* | 17000 | 11000 | 2900 | 730 | — | 850 | 120 | — | |
| 9727-E20 | N8000* | — | 20000 | — | 1400 | — | 1600 | — | — | |
| 9727-C62 | N15000†* | 68000 | 41000 | 11000 | 2600 | — | 3000 | 360 | — | |
| 9727-E25 | N30000* | 120000 | 70000 | — | 4700 | — | 5400 | — | — | |
| 9727-E27 | N62000 | — | 200000 | — | 13000 | — | — | 1600 | — | |
| 9727-E29 | N150000 | — | 420000 | — | 24000 | — | — | 3000 | — | |
| 9727-E30 | N190000 | 840000 | 520000 | 140000 | 33000 | — | — | 4000 | — | |
| 9727-E35 | N450000 | — | 1600000 | — | 100000 | 2350 | — | — | — | |
| 9727-E40 | N2700000 | — | 5300000 | — | 340000 | — | — | — | — | |
| 9727-E42 | N2700000SP | Dynamic shear rheometer (DSR) standard at 52 °C, 58 °C, 64 °C, 70 °C and 76 °C. | ||||||||
* Density values provided at all test temperatures for indicated standard
† Viscosity data for additional temperatures provided with these standards are listed in General Viscosity tables.
