CCS Low Temperature Viscosity Table
Low temperature CCS viscosity standards are used for measuring dynamic viscosity (in mPa·s or cP) at temperature from −5 °C to −40 °C. They are used to calibrate the CANNON Cold-Cranking Simulator (CCS) for oil testing per ASTM D5293, Apparent Viscosity of Engine Oils and Base Stocks Between −5 °C and −35 °C Using Cold-Cranking Simulator and SAE specification J300. Lot specific viscosity data in mPa·s (cP) is provided with each standard.
Nominal viscosity values (in mPa·s or cP) of low temperature viscosity CCS standards for ASTM D5293 and SAE specification J300
| Catalog Number | Viscosity Standard | −40 °C | −35 °C | −30 °C | −25 °C | −20 °C | −18 °C | −15 °C | −10 °C | −5 °C |
|---|---|---|---|---|---|---|---|---|---|---|
| 9727-N02 | CL080 | 1430 | 850 | — | — | — | — | — | — | — |
| 9727-N04 | CL090 | 1930 | 1150 | — | — | — | — | — | — | — |
| 9727-N06 | CL100 [CL10] | 2450 | 1450 | 875 | — | — | — | — | — | — |
| 9727-N07 | CL110 | 2880 | 1680 | 1030 | — | — | — | — | — | — |
| 9727-N08 | CL120 [CL12] | 3580 | 2050 | 1230 | 775 | — | — | — | — | — |
| 9727-N09 | CL130 | 4580 | 2600 | 1550 | 975 | — | — | — | — | — |
| 9727-N10 | CL140 [CL14] | 6380 | 3550 | 2080 | 1300 | 775 | 675 | — | — | — |
| 9727-N11 | CL150 | 7830 | 4310 | 2500 | 1530 | 950 | — | — | — | — |
| 9727-N12 | CL160 | 10300 | 5580 | 3200 | 1900 | 1200 | 1000 | — | — | — |
| 9727-N13 | CL170 | 12000 | 6430 | 3650 | 2180 | 1330 | — | 850 | — | — |
| 9727-N14 | CL190 [CL19] | 15900 | 8380 | 4680 | 2750 | 1680 | 1400 | 1080 | — | — |
| 9727-N16 | CL200 | 21100 | 10900 | 6030 | 3500 | 2130 | — | 1330 | 875 | — |
| 9727-N18 | CL220 [CL22] | — | 13600 | 7380 | 4230 | 2550 | 2050 | 1600 | 1030 | — |
| 9727-N20 | CL240 | — | 16900 | 9100 | 5180 | 3050 | — | 1900 | 1230 | — |
| 9727-N22 | CL250 [CL25] | — | 20000 | 10700 | 6000 | 3500 | 2880 | 2180 | 1380 | — |
| 9727-N24 | CL260 | — | — | 13100 | 7300 | 4300 | — | 2650 | 1680 | — |
| 9727-N26 | CL280 [CL28] | — | — | 16500 | 9080 | 5280 | 4300 | 3200 | 2030 | — |
| 9727-N28 | CL300 | — | — | 20700 | 11300 | 6480 | — | 3880 | 2430 | — |
| 9727-N30 | CL320 [CL32] | — | — | 26500 | 14300 | 8150 | 6600 | 4850 | 3000 | — |
| 9727-N31 | CL340 | — | — | — | 17000 | 9580 | — | 5650 | 3480 | — |
| 9727-N32 | CL380 [CL38] | — | — | — | 20800 | 11600 | 9330 | 6800 | 4180 | 2650 |
| 9727-N33 | CL420 | — | — | — | — | 14000 | — | 8180 | 4950 | — |
| 9727-N34 | CL480 [CL48] | — | — | — | — | 17400 | 13700 | 10100 | 6000 | 3780 |
| 9727-N35 | CL530 | — | — | — | — | 22000 | — | 12500 | 7500 | — |
| 9727-N36 | CL600 [CL60] | — | — | — | — | — | 20300 | 15700 | 9300 | 5700 |
| 9727-N37 | CL680 | — | — | — | — | — | — | 19400 | 11300 | — |
| 9727-N38 | CL740 [CL74] | — | — | — | — | — | — | — | 12600 | 7650 |
| 9727-N43 | Set of 18 | Set of CCS-2050/2100 low temp standards (includes CL080, CL090, CL100, CL110, CL120, CL130, CL140, CL150, CL160, CL190, CL220, CL250(2), CL280, CL320, CL380, CL480 and CL600) | ||||||||
This table presents nominal data. Actual values, provided with each standard, may vary slightly from lot to lot and formulations are subject to change. If your application requires close conformity with published nominal values, please contact technical service to obtain the actual viscosity values associated with the current formulation.
